Quick Cable Cabling and Accessories

REAL PEOPLE - WWW.THESOLARBIZ.COM - 888-826-0939

With forty-one years experience of making battery cables for the over the road heavy truck industry we don't solder our cables because a soldered connection puts solder between the wire and the lug. Solder is not as good a conductor as copper. A copper to copper twelve ton crimped connection is the best because, it carries more amperage and it's UL Listed.

Pairs of UL Listed custom made cables of the finest Quick Cable brand black code approved flexible cable, (4) four crimped MagnaLug lugs with red and black heat shrink tubing. Our UL Listed crimped MagnaLug lugs make the best connection because they are hands down, the thickest, heaviest, most durable and conductive lug in the world.

Our code approved custom cable sets are, beyond a doubt, the best you can buy. They will serve your system  well for many years to come.

The UL Listed Marine Grade Tinned Cable sets below are made for most of the OutBack Inverters and Breaker Boxes.  We will custom make any cable length you require in 4 ga, 2 ga, 2/0 ga and 4/0 ga UL Listed Ultra-flex cable. Call 888-826-0939 to discuss your needs and for pricing.

Additional crimped MagnaLug lugs with heat shrink tubing are available.  We can cut cables to any length to accommodate your fuses, breakers or shunts. Tell us your needs when you order.

Battery Cable - Interconnects

Highest quality multi-stranded copper welding cable with twelve ton crimped tinned copper lugs and heat shrink tubing on both ends. Our crimped copper lugs make the best connection because they are a copper to copper connection.

After over thirty years experience of making battery cables for the over the road heavy truck industry we don't solder our cables because a soldered connection puts solder between the wire and the lug and solder is not as good a conductor as copper. A copper to copper twelve ton crimped connection is the best because, it carries the most amperage.

We have listed the two most popular sizes below. The 8.5 inch is commonly used to series connect T-105, L-16 and other batteries. The 17 inch is usually used for parallel connections.

We will custom make any gauge and length interconnect you require, using superior quality MagnaLugs and Heavy duty Heat Shrink, call 888-826-0939 to order.

• Wider pad for better electrical contact, thicker pad for greater strength and conductivity

• Exceeds SAE conductivity standards J163 and J1811

• MagnaLugs are UL Listed, when applied with Crimp tool

  ---

Acid Spill Absorber & Neutralizer

This amazing product is way beyond anything else on the market you could use. For years all we had to recommend to folks was, to sprinkle baking soda on the floor underneath their battery installation. The result was marginal at best.

Now you can spread our acid spill absorber & neutralizer with confidence that any spill will be contained and neutralized. The formula changes color when acid is present and then changes color again when the acid is neutralized. No guessing that it worked... you see visual proof it has done its job. We sell the 8 pound bucket which should be enough for the life of your batteries.

We recommend spreading the formula on the floor under your protective floor mat and then on top of the mat as well. Then place you batteries directly on the formula. Or in the case of HuP Solar One batteries also sprinkle into the bottom of the cans as well. Any spillage will be quickly absorbed and neutralized.

• Ultra Polymer Absorber is safe and non hazardous.

• Sweeps up clean and dry, not dusty like kitty litter.

• Specifically formulated to neutralize Sulfuric Acid

• Does NOT create asphyxiating Carbon Dioxide Gas

Part Number TSB-510130

QuickCote+ Protective Compound

QuickCote+ Protective compound for battery terminals and connections.  Special Formula seals terminals and connections against corrosion, moisture, dirt and oil.

Brush on application stays put, won't drip of evaporate. Use on all exposed electrical terminals and connections. Also prevents seizing of fasteners.

8 Ounce Can with Applicator Brush, will coat one HUP Solar One 12 volt battery, for 24 volt order two cans etc.

Part Number TSB-06023

Floor Protective Battery Mat

Everybody who sets up a battery system always asks... What should I put under my batteries to protect my floor?

Here's the answer... Our acid absorbing battery mat! We sell it in a convenient 3 foot by 10 foot roll. A perfect size for most battery installations. Can be cut to size.

In the event of a battery spill use our wash water neutralizer TSB-510160 to neutralize acid and then shop-vac to remove liquid and reuse mat again. Will last the life of many battery installations. Cheaper than a truck bed mat, and it absorbs acid spills too.

• Mat absorbs Acid but won't leak through tough Polypropylene backing.

• Electrically isolates batteries, preventing parasitic discharge.

• Use over and over again.

• Protects floors and equipment from acid corrosion.

Part Number TSB-510170

Eyewash Station

Setting up a renewable energy battery system? Don't forget this most important item! I recommend placing our Eyewash Station where you can easily find it blind, if you get acid in your eyes. Just grab the bottle of sterile eyewash and irrigate your eyes. You can't buy new eyes... This is the most important part of your battery system get one now, don't risk your precious eyes.

Part Number TSB-510521

Add to wash water to neutralize acid spills on our Floor Protective Battery Mat or anywhere you have a sulfuric acid spill. Once neutralized just suck it up with your shop-vac and your done.

Use on the battery box in your car or truck.  When I have new batteries delivered, I always wash the sides and bottom of the batteries before I put them into service. Never wash the tops of your batteries as you do not want any neutralizer to get into the cells, because it will damage them.

If you're quick it may even save your new blue jeans!

• Use to pH Adjust Wash Water. See POTW, DOT, & EPA
• Concentrated acid neutralizer
• Non-corrosive/Non-hazardous
• Allows for re-use of wash water
• In 1 gallon bottles
• Also used to remove acid from concrete floors and drip pans

Part Number TSB-510160 (Discontinued Item)

Liquid Electrical Tape

New 8 oz. resealable can with applicator brush lid. Electrically insulates to over 1100 Volts per mil. Liquid Electrical Tape is a dielectrical coating which seals out moisture when used on electrical connections, outdoor connectors, vehicle repairs, light connections and to water/weatherproof wire nut connectors. Use to repair damaged cord casings. Water/weatherproof landscape & pool wiring, Marine wiring  connections, etc. Excellent acid, alkaline and abrasion resistance.  We highly recommend Liquid Tape over any other weatherproofing for cables and connectors!

Important Note: This item is considered a potential hazard in liquid form and must ship by UPS ground transportation only.

Part number VEE-95209 (Discontinued Item)

Cold Fusing Shrink Tape

Black cold fusing shrink tape so heat is not required to shrink. Excellent for waterproofing the MC Connectors on your solar modules. Seals out moisture and insulates up to 450 volts. Tape is 3/4 inch wide in a 30 foot roll. Can be used in any application where you may have used heat shrink tubing except for underwater well pump connections. available in single rolls or discounted in lots of 5

Single roll Part number VEE-70560

Lots of 8 Part number VEE-S109-70560

Manual Cable Crimper

Part number TSB-42660

QuickStrip Cable Striper

This has got to be the coolest little tool for easily stripping insulation from large single conductor cable, without damaging the conductor itself.  QuickStrip™ cable stripper by Quick Cable This tool easily strips from 10 gauge wire up to 4/0 cable.

Simple to use. It cuts through the insulating jacket without damaging the conductors. Includes a spare blade in the handle. I have been using a cable stripper tool for years  and I have not found a better way to strip larger cable.

Part number TSB-42150

Ground Lay-in Lugs

Manufactured exclusively for The Solar Biz.

SIS-50501 A very necessary Grounding Lug for grounding solar module frames together. Manufactured exclusively for The Solar Biz. A hard to find UL listed item. WILL NOT RUST!!

Fasten to the module with the stainless hardware usually supplied with the module to the ground hole on the rear of all of your solar modules... lay in your solid bare copper ground wire (will accept from 4 ga to 14 ga copper wire).

• Manufactured from high strength Tinned Aluminum Alloy with non-magnetic stainless steel screw.
• UL listed
• Lay-in feature for ease in installation.
• For copper conductor.
• Rated for 600 Volts.
• Tin plating.
• BULK 1000 lot pricing available for other dealers.

Part number SIS-50501 no longer stocked, alterative replacement item WIE-10050

We carry the full line of Quick Cable MagnaLugs. Call for Other Sizes and Types.

Bulk Cable

Sold by the foot  Stranded single conductor UL Listed copper wire as described below. All the wire listed below is super flexible

Quick Disconnects with Lugs

Industrial Battery Connectors Original crimp style. Final assemblies meet UL and CSA specifications when all components are made and crimped with a UL Listed tool. Polarity keyed disconnects. Requires 2 per connection. Housings are supplied in gray, but, are available in red and blue on special order.

IPS Class T Fuse System

The IPS® Class T Fuse Block is designed to provide code compliant over-current protection for mobile applications. It protects the battery bank, inverter and cables from damage caused by short circuits and overloads. It uses a fast acting, current limiting class T fuse cartridge which provides instantaneous protection in the event of a short circuit but also employs a time delay to allow momentary current surges common in inverter applications.

The Solar Biz, offers a complete line of IPS® class "T" fuse blocks. Available in 110, 200, 300, 350 and 400 amp models. IPS® fuse blocks are ideal in mobile applications where over-current protection is required for high current components such as inverters and chargers. A rugged GE Lexan®940 injection molded base and thermoformed Abex 700 ® ABS cover provide durability, easy installation and good looks all in a compact, cost effective package.

Fuses must be connected in the main positive battery cable between the battery bank and the Inverter, for all inverter installations, regardless of battery voltage. We offer these economical fuses and fuse holders as an alternative to expensive large breakers and breaker boxes.

We can offer substantial quantity discounts for 30 or more of these items call 888-826-0939 for pricing

DC Rated Fuses

Fuses Are Required ...on all wiring. If you aren't fused, your are risking a fire and perhaps an explosion. If you have insurance and have a fire you may not qualify for the insurance you paid for. If the claims adjuster finds wiring not to Code they cancel your insurance!

DC RATED Fuses

Not all fuses are created equal. Yes... you may be able to save some money by purchasing AC fuses at the local hardware, or at some other electrical or marine outlet. But if you really want protection, use a fuse designed for DC systems, not AC. We offer these DC fuses exclusively.

Size for In-Rush Loads

These fast acting fuses can either bolt to your battery terminal or distribution lugs and provide the protection you need. Because they are fast acting, they must be sized for in-rush loads.

DC Breaker Box and Breakers

Got a real small DC only system and only need a few breakers?... here's your answer.  Here is very handy impossible to find item. It is a small DC/AC breaker box. Will accept 1 to 4 either DC or AC din rail mount breakers. 3/4-1 inch knockouts top and bottom. Small size 3" X 3" X 7"  Weight 2 Lbs. Rated for indoor use only. Order breakers separately. See below.

The 63 amp breaker listed below can be used with the Outback MX-60 Charge controller. So if you need to add another charge controller to your ever expanding system and were wondering where the breakers were going to go in your full DC breaker box... here's your answer

I have only listed the DC breakers below but we also carry AC din rail mount breakers for the same price as the DC. Call 888-826-0939 with your needs.

Power Vent

Battery Bank Ventilation
Ventilates hydrogen that's naturally generated through the charging of your battery bank. Prevents dangerous build up of explosive hydrogen gas. Uses very little power. Guaranteed for 4 years. Choice of 12, 24 or 48V DC models.

The POWER VENT was designed for use in remote home power systems. The concept arose from field experience of systems with enclosed battery boxes. Quite often the NEC required venting was found back drafting, thus cooling the battery bank and lowering its' capacity as well as venting hydrogen gas into the structure.

POWER VENT alleviates this condition by keeping a gravity operated damper closed within the vent pipe except at times when the batteries are being charged and producing hydrogen gas. During these times the battery box is force vented with a low power, sparkless fan which overcomes the damper sending the gas outdoors. The "fan on" mode is determined by the battery voltage. When the batteries are "gassing" during charge periods the battery voltage will read above normal. A voltage sensitive switch is required in the system to make the on/off determination. All TRACE SW model inverters have a programmable auxiliary relay which can operate the POWER VENT. Other systems require the addition of a voltage controlled switch.

See Installation Diagram
